SURSA ASUS ROG STRIX 1200W 80+ GOLD Intel Form Factor ATX12V ATX 3.0 Yes Dimensions 180 x 150 x 86 mm Efficiency 80Plus Gold Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 22A 22A 100A 0.3A 3A

SURSA ASUS ROG STRIX 1200W 80+ GOLD Intel Form Factor ATX12V ATX 3.0 Yes Dimensions 180 x 150 x 86 mm Efficiency 80Plus Gold Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 22A 22A 100A 0.3A 3A Combined Load 120W 120W 1200W 3.6W 15W Total Output 1200W Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 4 SATA x 5 PERIPHERAL x 4 Package Contents Power Cord x 1 Motherboard Power Cable x 1 (600mm) CPU Cable x 2 (650mm) PCI-E Gen 5 16-pin Cable x 1 (700mm) PCI-E 1-to-1 Cable x 2 (700mm) PCI-E 1-to-2 Cable x 1 (700mm) SATA 1-to-2 Cable x 1 (400+120mm) SATA 1-to-3 Cable x 1 (400+120+120mm) Peripheral 1-to-4 Cable x 1 (400+150+150+150mm) Addressable RGB Cable x 1 (800mm) User Manual x 1 Weight 3.23 kg (single PSU) AURA SYNC ARGB 0dB Fan Button Yes Cybenetics Noise Level Certification A+

Standard

80Plus-Gold

Connectivity

Yes

PFC

Active

PSU Power

751W - 1000W

PSU Type

ATX

RGB

DA
