E16 G2 U5-125U WUXGA 16 512 3YO DOS

E16 G2 U5-125U WUXGA 16 512 3YO DOS

Audio Chip

High Definition (HD) Audio, Senary SN6141 codec

Green Certifications

ErP Lot 6

Ethernet

100/1000M (RJ-45)

Display

16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC

Camera

FHD 1080p + IR Hybrid with Privacy Shutter

Power Adapter

65W USB-C® (3-pin)

Other Certifications

TÜV Rheinland® Low Blue Light (Software Solution)

Fingerprint reader

Touch Style, Match-on-Chip, Integrated in Power Button

Storage Support

Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB

Card Reader

No card reader

Speakers

Stereo speakers, 2W x2, Dolby Atmos®, audio by HARMAN

Case Color

Black

Dimensions (WxDxH)

356.1 x 247.7 x 19.85 mm (14.02 x 9.75 x 0.78 inches)

AI PC Category

AI PC

NPU

Intel® AI Boost, up to 11 TOPS

Storage Slot

Two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot

Standard Ports

1x USB-A (USB 5Gbps / USB 3.2 Gen 1)

Chipset

Intel® SoC Platform

Optical

None

Microphone

2x, Array

Bundled software

None

Memory slots

Two DDR5 SO-DIMM slots, dual-channel capable

Graphics

Integrated Intel® Graphics

Battery

Integrated 57Wh

Keyboard

Backlit, English (EU)

SIM Card

None

NFC

None

Security Chip

Discrete TPM 2.0 Enabled

Physical Locks

Kensington® Nano Security Slot™, 2.5 x 6 mm

Mil-Spec Test

MIL-STD-810H military test passed

Weight

Starting at 1.81 kg (3.99 lbs)

WWAN

None

Included Upgrade

3Y Onsite upgrade from 1Y Courier/Carry-in Windchill (CPN)

Memory

1x 16GB SO-DIMM DDR5-5600

Max Memory

Up to 64GB DDR5-5600

Storage

512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0

Docking

Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit

System Management

Non-vPro®

Processor

Intel® Core™ Ultra 5 125U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.3GHz, 12MB

Smart card reader

None

Base Warranty

1-year, Courier or Carry-in

Operating System

None
